GIGABYTE B760M AORUS PRO AX WIFI DDR5 LGA1700 Micro-ATX Motherboard
R4334,00
- CPU: Supports 14th, 13th & 12th Gen Intel Core, Pentium Gold & Celeron Processors
- Socket: LGA1700
- Chipset: Intel B760
- Memory: 4 x DIMM slots | Max. 256GB | DDR5 7800(O.C.)
- Storage: 2 x M.2 slot | 4 x SATA 6Gb/s ports
- Expansion Slots: 2 x PCIe 4.0 x16
- Network: 1 x Ethernet 2.5 Gbps | Wireless: Wi-Fi 6E (802.11ax) & Bluetooth v5.3
- Warranty: 3 Years
Secure Payments via Bob Pay
Visa
Mastercard
Amex
Scan to Pay
PayShap
Banking Apps
Save 2.5% paying via EFT — you save R108.35 on this order
- Description
- SPECS
- Brand
- Reviews (0)
Description
GIGABYTE B760M AORUS PRO AX: Unleash Elite DDR5 Power in Micro ATX Form
The GIGABYTE B760M AORUS PRO AX motherboard brings top-tier performance to compact builds, supporting 14th, 13th, and 12th Gen Intel Core processors with cutting-edge DDR5 memory. Its robust Twin 14+1+1 Phases Digital VRM Solution ensures stable power delivery, making it a premier choice for Micro ATX gaming enthusiasts and power users seeking next-generation capabilities.
Unique Features
- Unparalleled Performance：Twin 14+1+1 Phases Digital VRM Solution: Delivers exceptionally stable and robust power to the CPU, perfect for maximizing the performance of Intel’s latest processors in demanding Micro ATX gaming and creation setups.
- Dual Channel DDR5：4 SMD DIMMs with XMP 3.0 Memory Module Support: Leverages next-generation DDR5 memory with enhanced signal integrity and XMP 3.0 for extreme speeds and superior system responsiveness, pushing the boundaries of performance.
- Next Generation Storage：2 PCIe 4.0 x4 M.2 Connectors: Provides dual ultra-fast storage options with two PCIe 4.0 M.2 slots, ensuring rapid game loading times and swift data access for all your applications.
- Advanced Thermal Design & M.2 Thermal Guard ：To Ensure VRM Power Stability & M.2 SSD Performance: A comprehensive cooling solution, featuring large VRM heatsinks and an M.2 thermal guard, maintains peak performance and system stability under intense workloads.
- EZ-Latch Plus：M.2 Connectors with Quick Release & Screwless Design: Simplifies M.2 SSD installation and upgrades with an innovative, user-friendly tool-free mechanism, significantly enhancing the building and maintenance experience.
- Fast Networks：2.5GbE LAN & Wi-Fi 6E 802.11ax: Offers versatile, high-speed network connectivity with low-latency 2.5GbE LAN and cutting-edge Wi-Fi 6E technology for a seamless and responsive online experience.
- Extended Connectivity：Front USB-C 10Gb/s, Rear USB-C 20Gb/s, DP, HDMI: Provides a rich selection of modern connectivity options, including high-speed USB-C on both the rear panel (20Gb/s) and an internal header for front panel access (10Gb/s).
- Smart Fan 6：Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP: Delivers intelligent and customizable cooling for optimal thermal performance and quiet operation, even in compact Micro ATX gaming systems.
- Q-Flash Plus：Update BIOS Without Installing the CPU, Memory and Graphics Card: Allows for easy and convenient BIOS updates for new hardware compatibility without needing older components installed, ensuring your system is always up-to-date.
Quick Specs of the GIGABYTE B760M AORUS PRO AX
| Specification | Details |
|---|---|
| CPU Support | Intel Socket LGA1700 for Intel Core 14th, 13th, 12th Gen, Pentium Gold and Celeron Processors |
| Socket | LGA1700 |
| Chipset | Intel B760 |
| Memory Support | 4 x Dual Channel DIMM slots, up to 256GB, DDR5 (7800(OC) to 4000MT/s) |
| Storage Options | 2 x M.2 slots | 4 x SATA 6Gb/s ports |
| Display Ports | 1 x HDMI port | 1 x DisplayPort |
| USB Ports | 1 x USB 3.2 Gen 2×2 (Type-C) | 1 x USB 3.2 Gen 2 (Type-A) | 3 x USB 3.2 Gen 1 (Type-A) | 4 x USB 2.0/1.1 (Type-A) |
| Expansion Slots | 1 x PCIe 4.0 x16 slot | 1 x PCIe 4.0 x16 slot (x4 mode) |
| LAN | 1 x Realtek 2.5GbE LAN chip |
| Wireless | Wi-Fi 6E (Intel AX211 / Realtek RTL8852CE); Bluetooth v5.3 |
| Audio | Realtek Audio CODEC |
| Form Factor | Micro ATX |
Check out full specifications under the Specs tab.
Why Choose This Product?
The GIGABYTE B760M AORUS PRO AX is engineered for enthusiasts who demand elite performance in a compact Micro ATX form. It harnesses the power of DDR5 memory and Intel’s latest CPUs, backed by a robust VRM and advanced thermal design, making it ideal for high-end gaming and creative tasks.
With dual PCIe 4.0 M.2 slots, Wi-Fi 6E, and 2.5GbE LAN, this board ensures lightning-fast storage and network capabilities. User-centric features like EZ-Latch Plus make it a top choice for building a powerful, feature-rich, and future-proof Micro ATX system that doesn’t compromise on AORUS quality.
Build your ultimate compact rig with the GIGABYTE B760M AORUS PRO AX. Experience next-generation DDR5 power and professional-grade features today!
| CPU | LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors* L3 cache varies with CPU * Please refer to “CPU Support List” for more information. |
| Chipset | Intel B760 Express Chipset |
| Memory |
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” for more information.) |
| Onboard Graphics | Integrated Graphics Processor-Intel HD Graphics support:
* Support for HDMI 2.1 version and HDCP 2.3.
* Support for DisplayPort 1.2 version and HDCP 2.3 |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
| LAN | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | Intel Wi-Fi 6E AX211 (For PCB rev. 1.0) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rateRealtek Wi-Fi 6E RTL8852CE (For PCB rev. 1.1) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate (Actual data rate may vary depending on environment and equipment.) |
| Expansion Slots | CPU:
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset:
|
| Storage Interface | CPU:
Chipset:
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB | Chipset:
Chipset+USB 3.2 Gen 1 Hub:
Chipset+USB 2.0 Hub:
|
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderbolt add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) 1 x reset button 1 x Q-Flash Plus button 1 x Clear CMOS jumper 1 x reset jumper |
| Back Panel Connectors | 1 x USB Type-C port, with USB 3.2 Gen 2×2 support 1 x USB 3.2 Gen 2 Type-A port (red) 3 x USB 3.2 Gen 1 ports 4 x USB 2.0/1.1 ports 2 x SMA antenna connectors (2T2R) 1 x HDMI port 1 x DisplayPort 1 x RJ-45 port 1 x optical S/PDIF Out connector 2 x audio jacks |
| I/O Controller | iTE I/O Controller Chip |
| H/W Monitoring | Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control * Whether the fan speed control function is supported will depend on the cooler you install. |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus |
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit Support for Windows 10 64-bit |
| Form Factor | Micro ATX Form Factor |
