GIGABYTE B850M AORUS ELITE WIFI6E ICE DDR5 AM5 Micro-ATX Motherboard
R4587,00
- CPU: Supports AMD Ryzen 9000 / Ryzen 8000 / Ryzen 7000 Series Processors
- Socket: AM5
- Chipset: AMD B850
- Memory: 4 x DIMM sockets | Max. 256GB | DDR5 8200(O.C) MT/s
- Storage: 2 x M.2 slots | 4 x SATA 6Gb/s connectors
- Expansion Slots: 1 x PCIe 5.0 x16 | 1 x PCIe 3.0 x16
- Network: 1 x Ethernet 2.5 Gbps | Wi-Fi 6E (802.11ax) & Bluetooth v5.3
- Warranty: 3 Years
- Description
- SPECS
- Brand
- Reviews (0)
Description
GIGABYTE B850M AORUS ELITE WIFI6E ICE: Compact Form, Icy Performance
Craft the ultimate white-themed gaming rig with the GIGABYTE B850M AORUS ELITE WIFI6E ICE. This Micro-ATX motherboard is engineered to deliver elite performance for AMD Ryzen 9000, 8000, and 7000 series processors, all while boasting a stunning all-white PCB and silver heatsinks. It features a formidable Digital Twin 12+2+2 phases VRM solution, support for extreme DDR5 overclocking up to 8200MT/s, and next-generation PCIe 5.0 and Wi-Fi 6E technology. A comprehensive suite of EZ-Latch designs makes this powerhouse incredibly easy to build with, proving that top-tier performance can also come with unparalleled style and convenience.
Unique Features
- Digital twin 12+2+2 phases VRM solution：Provides clean, stable, and highly efficient power to the CPU, unlocking the full potential of high-performance AMD processors for elite gaming and content creation.
- DDR5 OC up to 8200MT/s：With support for AMD EXPO and XMP, this board allows you to push DDR5 memory to its limits for the ultimate in-game performance and system responsiveness.
- EZ-Latch Plus & Click：A complete suite of quick-release and screwless designs for the PCIe slot, M.2 connectors, and M.2 heatsinks makes installing and upgrading your components faster and easier than ever.
- WIFI EZ-Plug：This quick and easy design for the Wi-Fi antenna installation removes the hassle of tiny, hard-to-turn connectors, streamlining your build process.
- Ultra-Fast Storage：Two M.2 slots, including a primary PCIe 5.0 x4 connector, provide an expansive and incredibly fast storage solution for your entire game library and applications.
- Efficient Thermal：VRM Thermal Armor Advanced and an extended M.2 Thermal Guard, finished in silver, ensure that your critical components stay cool while perfectly complementing the ICE aesthetic.
- Fast Networking：Get the best of both worlds with a high-speed 2.5GbE LAN port and cutting-edge Wi-Fi 6E with an ultra-high gain antenna for the fastest, lowest-latency connections.
- PCIe UD Slot：The primary PCIe 5.0 x16 slot features an ultra-durable design with 10X strength, providing superior support for heavy graphics cards and enhancing heat dissipation.
- Sensor Panel Link：An onboard video port allows for hassle-free setup of in-chassis sensor panel displays, letting you monitor your system’s performance in style.
Quick Specs of the GIGABYTE B850M AORUS ELITE WIFI6E ICE
| Specification | Details |
|---|---|
| CPU Support | Supports AMD Ryzen 9000/8000/7000 Series Processors |
| Socket | AM5 |
| Chipset | AMD B850 |
| Memory Support | 4 x DDR5 DIMMs | up to 256GB | DDR5 8200(O.C.) |
| Storage Options | 2 x M.2 slots | 4 x SATA 6Gb/s connectors |
| Display Ports | 1 x DisplayPort 1.4 |
| USB Ports | 1 x USB 3.2 Gen 2 (Type-C) | 2 x USB 3.2 Gen 2 (Type-A) | 5 x USB 3.2 Gen 1 (Type-A) | 4 x USB 2.0/1.1 (Type-A) |
| Expansion Slots | 1 x PCIe 5.0 x16 | 1 x PCIe 3.0 x16 (runs at x4) |
| LAN | Realtek 2.5GbE LAN |
| Wireless | Realtek Wi-Fi 6E (802.11ax) | Bluetooth v5.3 |
| Audio | Realtek ALC1220/Audio CODEC (rev. dependent) |
| Form Factor | Micro ATX |
Check out full specifications under the Specs tab.
Why Choose This Product?
The GIGABYTE B850M AORUS ELITE WIFI6E ICE is engineered for elite gaming performance and stunning aesthetics. Its powerful digital twin VRM and advanced thermal armor provide a rock-solid foundation for the latest multi-core AMD Ryzen processors, while support for extreme DDR5 overclocking lets you push your system to its absolute limits. With PCIe 5.0 for both the graphics card and M.2 SSD, you’re investing in a platform that’s ready for years of top-tier gaming in a compact form factor.
This motherboard sets a new standard for a user-friendly building experience, all wrapped in a gorgeous all-white ICE design. The full suite of EZ-Latch designs for the PCIe slot and M.2 connectors makes installation and upgrades completely tool-free and effortless. Innovative features like the WIFI EZ-Plug and Sensor Panel Link add a level of thoughtful design that simplifies every part of the process. Combined with ultra-fast Wi-Fi 6E and 2.5GbE LAN, this is the ultimate motherboard for builders who demand both power and a frustration-free experience.
| Model Name | B850M AORUS ELITE WIFI6E ICE |
| CPU | AMD Socket AM5, support for:
(Go to GIGABYTE’s website for the latest CPU support list.) |
| Chipset | AMD B850 |
| Memory |
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” on GIGABYTE’s website for more information.) |
| Onboard Graphics | Integrated Graphics Processor with AMD Radeon Graphics support:
* Support for DisplayPort 1.4 version and HDR.
* Support for HDMI 1.4 version. (Graphics specifications may vary depending on CPU support.) |
| Audio | Realtek Audio CODEC (Only for rev. 1.0) High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF OutRealtek ALC1220 CODEC(Only for rev. 1.1) * The back panel line out jack supports DSD audio. High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
| LAN | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | Realtek Wi-Fi 6E RTL8852CE
(Actual data rate may vary depending on environment and equipment.) |
| Expansion Slots | 1 x PCI Express x16 slot (PCIEX16), integrated in the CPU:
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot.Chipset:
|
| Storage Interface | 1 x M.2 connector (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type 25110/22110/2580/2280 SSDs:
1 x M.2 connector (M2B_CPU), integrated in the CPU, supporting Socket 3, M key, type 22110/2280 SSDs:
4 x SATA 6Gb/s connectors RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
| USB | CPU:
CPU+USB 2.0 Hub:
Chipset+USB 3.2 Gen 1 Hub:
Chipset:
|
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 2 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2×2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0/GC-TPM2.0 SPI V2 module only) 1 x HDMI port (Note) 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper(Note) Actual support may vary by CPU. |
| Back Panel Connectors | 1 x DisplayPort (Note) 1 x Q-Flash Plus button 4 x USB 2.0/1.1 ports 1 x USB Type-C port, with USB 3.2 Gen 2 support 5 x USB 3.2 Gen 1 ports 1 x RJ-45 port 2 x USB 3.2 Gen 2 Type-A ports (red) 2 x antenna connectors (2T2R) 2 x audio jacks 1 x optical S/PDIF Out connector(Note) Actual support may vary by CPU. |
| I/O Controller | iTE I/O Controller Chip |
| H/W Monitoring | Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan(pump) you install. |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup |
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit |
| Form Factor | Micro ATX Form Factor |
