GIGABYTE B860M AORUS ELITE WIFI6E ICE DDR5 LGA1851 Micro-ATX Motherboard
R4708,00
- CPU: Supports Intel Core Ultra Processors
- Socket: LGA1851
- Chipset: Intel B860
- Memory: 4 x DIMM slots | Max. 256GB | DDR5 9200(O.C.)
- Storage: 3 x M.2 slots | 4 x SATA 6Gb/s ports
- Expansion Slots: 1 x PCIe 5.0 x16 | 1 x PCIe 4.0 x16
- Network: 1 x Ethernet 2.5 Gbps | Wi-Fi 6E (802.11ax) & Bluetooth v5.3
- Warranty: 3 Years
- Description
- SPECS
- Brand
- Reviews (0)
Description
GIGABYTE B860M AORUS ELITE WIFI6E ICE: Chilling Performance, Stunning Design
The GIGABYTE B860M AORUS ELITE WIFI6E ICE edition combines the elite performance of the AORUS series with a stunning all-white and silver aesthetic. This Micro ATX motherboard is the perfect centerpiece for a visually striking yet compact powerhouse. Designed for Intel Core Ultra processors, it delivers a potent 12+1+2 VRM, next-generation PCIe 5.0 support, and a full suite of high-speed connectivity including Wi-Fi 6E and a versatile USB4 port, proving you don’t have to choose between performance and style.
Unique Features
- Digital twin 12+1+2 phases VRM solution： Delivers a robust and stable power supply to the CPU, ensuring peak performance during intense gaming and heavy multitasking.
- Dual Channel DDR5 Support： Four DIMM slots with XMP support allow you to harness the full power of high-speed DDR5 memory for ultimate system responsiveness.
- EZ-Latch Plus： This innovative quick-release and screwless design on the PCIe and M.2 slots makes installing or swapping components faster and easier than ever.
- Sensor Panel Link： An onboard front HDMI port provides a simple, hassle-free way to connect and set up an in-chassis monitoring panel.
- Ultra-Fast Storage： Three M.2 slots, headlined by a next-generation PCIe 5.0 slot, offer massive, high-speed storage capacity for all your games and applications.
- Efficient Thermal Design： A combination of advanced VRM heatsinks and an extended M.2 thermal guard, all in a stylish white finish, keeps critical components cool and ensures sustained performance.
- Fast Networking： Dominate online with a high-speed 2.5GbE LAN port and next-generation Wi-Fi 6E, providing flexible, low-latency network connections.
- Extended Connectivity： A cutting-edge USB4 Type-C port offers incredible versatility with high-speed data transfer and DisplayPort video output in a single connector.
Quick Specs of the GIGABYTE B860M AORUS ELITE WIFI6E ICE
| Specification | Details |
|---|---|
| CPU Support | Supports Intel Core Ultra Processors |
| Socket | LGA1851 |
| Chipset | Intel B860 |
| Memory Support | 4 x DDR5 DIMMs | up to 256GB | DDR5 9200(O.C.) |
| Storage Options | 3 x M.2 slots | 4 x SATA 6Gb/s ports |
| Display Ports | 1 x USB4 (DP Alt Mode) | 1 x DisplayPort | 1 x HDMI |
| USB Ports | 1 x USB4 (Type-C) | 2 x USB 3.2 Gen 2 (Type-A) | 4 x USB 3.2 Gen 1 (Type-A) | 4 x USB 2.0/1.1 (Type-A) |
| Expansion Slots | 1 x PCIe 5.0 x16 (CPU Dependent) | 1 x PCIe 4.0 x16 |
| LAN | Realtek 2.5GbE LAN |
| Wireless | Wi-Fi 6E (802.11ax) | Bluetooth v5.3 |
| Audio | Realtek Audio CODEC |
| Form Factor | Micro ATX |
Check out full specifications under the Specs tab.
Why Choose This Product?
This motherboard isn’t just about power; it’s a statement piece. The GIGABYTE B860M AORUS ELITE WIFI6E ICE is perfect for building a visually stunning all-white or silver-themed PC. The striking ICE aesthetic extends across the PCB and heatsinks without sacrificing the elite performance of the AORUS line, including a powerful VRM and full PCIe 5.0 support for your critical components. Get the best of both worlds: a PC that performs at the highest level and looks incredible.
Experience the power of a full-size ATX board in a space-saving Micro ATX form factor. This motherboard packs in a wealth of high-end features, including three M.2 slots for massive, high-speed storage, a versatile USB4 port for next-gen peripherals, and a full complement of networking with Wi-Fi 6E and 2.5GbE LAN. It’s the ideal choice for builders who demand a clean, powerful, and compact setup without any compromise on features or connectivity.
| Model Name | B860M AORUS ELITE WIFI6E ICE |
| CPU | LGA1851 socket: Support for Intel Core Ultra Processors (Go to GIGABYTE’s website for the latest CPU support list.) L3 cache varies with CPU |
| Chipset | Intel B860 Express Chipset |
| Memory |
(The CPU and memory configuration may affect the supported memory types, data rate (speed), and number of DRAM modules, please refer to “Memory Support List” on GIGABYTE’s website for more information.) |
| Onboard Graphics | Integrated Graphics Processor-Intel HD Graphics support:
* Support for DisplayPort 2.1 version.
* Support for DisplayPort 2.1 version.
* Support for HDMI 2.1 version and HDCP 2.3.
* Support for HDMI 1.4 version.
|
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings.Support for S/PDIF Out |
| LAN | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) |
| Wireless Communication module | Intel Wi-Fi 6E AX211 (PCB rev. 1.0)
Realtek Wi-Fi 6E RTL8852CE (PCB rev. 1.1)
(Actual data rate may vary depending on environment and equipment.) |
| Expansion Slots | CPU:
* The PCIEX16 slot can only support a graphics card or an NVMe SSD. If only one graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset:
|
| Storage Interface | CPU:
Chipset:
RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices |
| USB | CPU:
Chipset:
Chipset+USB 3.2 Gen 1 Hub:
Chipset+2 USB 2.0 Hubs:
|
| Internal I/O Connectors | 1 x 24-pin ATX main power connector 2 x 8-pin ATX 12V power connectors 1 x CPU fan header 1 x CPU fan/water cooling pump header 3 x system fan headers 1 x system fan/water cooling pump header 3 x addressable RGB Gen2 LED strip headers 1 x RGB LED strip header 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 2 x Thunderboltâ„¢ add-in card connectors 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI V2 module only) 1 x HDMI port* 1 x power button 1 x reset button 1 x Q-Flash Plus button 1 x reset jumper 1 x Clear CMOS jumper* Actual support may vary by CPU. |
| Back Panel Connectors | 4 x USB 2.0/1.1 ports 4 x USB 3.2 Gen 1 ports 1 x DisplayPort* 1 x USB4 USB Type-C port (DisplayPort*) 1 x HDMI port* 1 x RJ-45 port 2 x USB 3.2 Gen 2 Type-A ports (red) 2 x antenna connectors (2T2R) 2 x audio jacks 1 x optical S/PDIF Out connector* Actual support may vary by CPU. |
| I/O Controller | iTE I/O Controller Chip |
| H/W Monitoring | Voltage detection Temperature detection Fan speed detection Water cooling flow rate detection Fan fail warning Fan speed control * Whether the fan (pump) speed control function is supported will depend on the fan (pump) you install. |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Unique Features | Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.Support for Q-Flash Support for Q-Flash Plus Support for Smart Backup |
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
| Operating System | Support for Windows 11 64-bit |
| Form Factor | Micro ATX Form Factor |
