ASUS PROART Z890-CREATOR WIFI DDR5 LGA1851 ATX Motherboard

Name: ASUS ProArt Z890-CREATOR WIFI | Dual Thunderbolt 5 & Wi-Fi 7
Brand: ASUS
SKU: 90MB1JD0-M0EAY0
Price: 11853.00 ZAR
Availability: InStock

0 out of 5

( There are no reviews yet. )

R11853,00

CPU: Supports Intel Core Ultra Processors (Series 2)
Socket: LGA1851
Chipset: Intel Z890
Memory: 4 x DIMM slots | Max. 256GB | DDR5 9066+(OC)
Storage: 5 x M.2 slots | 4 x SATA 6Gb/s ports
Expansion Slots: 2 x PCIe 5.0 x16 | 1 x PCIe 4.0 x16
Network: 1 x Ethernet 10 Gbps | 1 x Ethernet 2.5 Gbps | Wi-Fi 7 (802.11be) & Bluetooth v5.4
Warranty: 3 Years

Availability: 4 in stock SKU: 90MB1JD0-M0EAY0 Category: Intel Motherboards

Secure Payments via Bob Pay

Visa

Mastercard

Amex

Apple Pay

Google Pay

Scan to Pay

PayShap

Banking Apps

Save 2.5% paying via EFT — you save R296.33 on this order

Add to wishlist

Description
SPECS
Brand
Reviews (0)

Description

ASUS PROART Z890-CREATOR WIFI: Your Vision, Accelerated

The ASUS ProArt Z890-CREATOR WIFI is the ultimate ATX motherboard for content creators, engineered to maximize the performance of Intel Core Ultra Series 2 processors. It combines a professional, elegant aesthetic with a massively powerful VRM and a comprehensive suite of cutting-edge connectivity. Featuring revolutionary dual Thunderbolt 5 ports, 10G Ethernet, Wi-Fi 7, and a full PCIe 5.0 ecosystem for graphics and storage, the ProArt Z890-CREATOR WIFI is the definitive core of a powerful workstation built to bring your creative vision to life without compromise.

Unique Features

Dual Thunderbolt 5 Ports: Immerse yourself in your creations with two revolutionary Thunderbolt 5 ports, offering up to 120 Gbps of bandwidth with Bandwidth Boost for connecting multiple 8K displays and high-speed storage arrays.
Ultrafast Networking: A complete networking solution with Marvell 10Gb Ethernet, Intel 2.5Gb Ethernet, and next-generation Wi-Fi 7 provides lightning-fast connectivity for local network storage, internet, and wireless devices.
Full PCIe 5.0 Support: A complete PCIe 5.0 implementation across two x16 slots and the primary M.2 slot gives unfettered bandwidth to the fastest graphics cards and SSDs available, eliminating bottlenecks in your creative workflow.
Robust Power Design: A 16+1+2+2 power stage design with ProCool II connectors and superior components ensures optimal power delivery, efficiency, and rock-solid stability for the most demanding high-core-count processors.
Five Onboard M.2 Slots: Build a colossal and ultra-fast storage array for your projects and assets with five M.2 slots, including one PCIe 5.0 slot, all cooled by effective heatsinks for sustained performance.
ProArt Creator Hub: A dedicated and exclusive software portal allows you to monitor your PC status, personalize settings, and optimize your workflow with an intuitive dashboard and quick-access creative tools.

Quick Specs of the ASUS PROART Z890-CREATOR WIFI

Specification	Details
CPU Support	Supports Intel Core Ultra Processors (Series 2)
Socket	LGA1851
Chipset	Intel Z890
Memory Support	4 x DDR5 DIMMs \| up to 256GB \| DDR5 9066+(OC)
Storage Options	5 x M.2 slots \| 4 x SATA 6Gb/s ports
Display Ports	1 x HDMI \| 2 x Thunderbolt 5 (USB-C) \| 1 x Thunderbolt 4 (USB-C)
USB Ports	2 x Thunderbolt 5 (Type-C) \| 1 x USB4/Thunderbolt (Type-C) \| 6 x USB 10Gbps (Type-A) \| 1 x USB 2.0 (Type-A)
Expansion Slots	2 x PCIe 5.0 x16 \| 1 x PCIe 4.0 x16
LAN	Marvell 10Gb Ethernet \| Intel 2.5Gb Ethernet
Wireless	Wi-Fi 7 (802.11be) \| Bluetooth v5.4
Audio	Realtek ALC1220P Codec
Form Factor	ATX (30.5 cm x 24.4 cm)

Check out full specifications under the Specs tab.

Why Choose This Product?

The ProArt Z890-CREATOR WIFI is a creator’s dream, built to handle massive data flows without breaking a sweat. Its crowning feature is the dual Thunderbolt 5 and single Thunderbolt 4/USB4 setup, offering unparalleled speed and versatility for connecting professional displays, high-speed storage arrays, and capture devices. This is the ultimate connectivity hub for any serious creative workflow, designed to accelerate your process from start to finish.

Underneath its elegant design lies a beastly 16+1+2+2 power stage design and an 8-layer PCB, providing the rock-solid stability needed for hours of rendering, editing, and compiling. With a full PCIe 5.0 ecosystem for your GPU and SSDs, plus dual high-speed LAN ports and Wi-Fi 7, every single component of your workstation will run at its absolute maximum potential, allowing you to focus on your creativity.

Elevate your creative workflow and build the ultimate content creation powerhouse with the ASUS ProArt Z890-CREATOR WIFI.

Model	ProArt Z890-CREATOR WIFI
CPU	Support Intel Core Ultra Processors (Series 2), LGA1851* Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** * Refer to ASUS for CPU support list. ** Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.
Chipset	Intel Z890 Chipset
Memory	4 x DIMM slots, max. 256GB, DDR5 Support up to 9066+MT/s (OC), Non-ECC, Un-buffered and Clocked Unbuffered DIMM (CUDIMM)* Dual channel memory architecture Supports Intel Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile III (AEMP III) Support DIMM Fit Support DIMM Flex * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit ASUS. ** Non-ECC, un-buffered DDR5 memory supports On-Die ECC function.
Graphics	1 x HDMI port 2 x Intel Thunderbolt 5 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs* 1 x Intel Thunderbolt 4 ports (USB Type-C) support DisplayPort and Thunderbolt video outputs**** * Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates. Supports 4K@60Hz as specified in HDMI 2.1 * Supports up to 2 x 8K@60HZ (DSC mode) + 1 x 4K@60HZ monitors with DP in. Supports up to 1 x 8K@60HZ (DSC mode) + 1 x 4K@60HZ monitors without DP in. For resolution support please check DisplayPort 2.1 specs. Thunderbolt 5 bandwidth is limited by DisplayPort 2.1 with up to 77.4 Gbit/s. We recommend chain-connecting the monitors using verified Thunderbolt cables. ** In Thunderbolt 4 mode, supports up to 8K@60Hz x1 with DSC, maximum total bandwidth up to 23.8Gbps, for resolution support please check DisplayPort 2.1 specs. In DP alt mode, supports up to UHBR20.When the Thunderbolt 5 port is used to output two displays via integrated graphics, the Thunderbolt 4 port on the motherboard will not be able to output any display. *** While installing the operating system, please ensure that your monitor is connected to the HDMI port on the back I/O panel or to a discrete graphics card.
Expansion Slots	Intel Core Ultra Processors (Series 2) * 2 x PCIe 5.0 x16 slots (supports x16 or x8/x8 modes) Intel Z890 Chipset* 1 x PCIe 4.0 x16 slot (supports x4 mode) * Please check the PCIe bifurcation table on the support site ASUS – To ensure compatibility of the device installed, please refer to ASUS for the list of supported peripherals.
Storage	Total supports 5 x M.2 slots and 4 x SATA 6Gb/s ports* Intel Core Ultra Processors (Series 2) * M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 5.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) Intel Z890 Chipset M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) M.2_4 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 modes) M.2_5 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 & SATA modes)** 4 x SATA 6Gb/s ports * Intel Rapid Storage Technology supports PCIe RAID 0/1/5/10, SATA RAID 0/1/5/10, M.2 slot from CPU only supports RAID 0/1/5. ** M.2_5 slot shares bandwidth with PCIe 4.0 x16 slot. When M.2_5 slot is operating, PCIe 4.0 x16 slot will be disabled.
Ethernet	1 x Marvell AQtion 10Gb Ethernet 1 x Intel 2.5Gb Ethernet ASUS LANGuard
Wireless & Bluetooth	Wi-Fi 7* 2×2 Wi-Fi 7 (802.11be) Supports 2.4/5/6GHz frequency band Support Wi-Fi 7 320MHz bandwidth, up to 5.8Gbps transfer rate. Bluetooth v5.4* Wi-Fi features may vary depending on the operating system. For Windows 11, Wi-Fi 7 will require 24H2 or later version for full functions, Windows 11 21H2/22H2/23H2 only supports Wi-Fi 6E. For Windows 10, only Wi-Fi 6 is supported. * Wi-Fi 6GHz frequency band and bandwidth regulatory may vary between countries. *** The Bluetooth version may vary, please refer to the Wi-Fi module manufacturer’s website for the latest specifications.
USB	Rear USB (Total 10 ports) 2 x Thunderbolt 5 ports (2 x USB Type-C) 1 x USB4 / Thunderbolt port (1 x USB Type-C) 6 x USB 10Gbps ports (6 x Type-A ) 1 x USB 2.0 port (1 x Type-A ) Front USB (Total 5 ports) 1 x USB 20Gbps (supports USB Type-C) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports USB Type-C power delivery output: max. 5V/3A
Audio	Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC* Impedance sense for front and rear headphone outputs Internal audio Amplifier to enhance the highest quality sound for headphone and speakers Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in) Supports up to 32-Bit/192 kHz playback* Audio Features Gold-plated audio jacks Premium audio capacitors Dedicated audio PCB layers * Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio. ** A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Back Panel I/O Ports	2 x Thunderbolt 5 USB Type-C ports 1 x USB4 / Thunderbolt Type-C port 6 x USB 10Gbps ports (6 x Type-A) 1 x USB 2.0 port (1 x Type-A) 1 x DisplayPort (Input only) 1 x HDMI port 1 x Wi-Fi module 1 x Marvell AQtion 10Gb Ethernet port 1 x Intel 2.5Gb Ethernet port 2 x Gold-plated audio jacks 1 x BIOS FlashBack button
Internal I/O Connectors	Fan and Cooling Related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 5 x 4-pin Chassis Fan headers Power Related 1 x 24-pin Main Power connector 2 x 8-pin +12V CPU Power connector Storage Related 5 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 20Gbps connector (supports USB Type-C) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 1 x USB 2.0 header supports 2 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen2 headers 1 x Clear CMOS button 1 x COM Port header 1 x CPU Over voltage jumper 1 x Chassis Intrusion header 1 x Front Panel Audio header (F_AUDIO) 1 x SPI TPM header (14-1 pin) 1 x 10-1 pin Front System Panel header 1 x Thermal Sensor header
Special Features	ASUS 5X PROTECTION III DIGI+ VRM (- Digital power design with DrMOS) ESD Guards LANGuard Overvoltage protection SafeSlot Stainless-steel back I/O ASUS Q-Design M.2 Q-Latch, M.2 Q-Release, M.2 Q-Slide, Q-Release Slim (with PCIe SafeSlot), Q-Antenna, Q-Connector, Q-Dashboard, Q-DIMM, Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) ASUS Thermal Solution M.2 heatsink backplate, M.2 heatsink, VRM heatsink design ASUS EZ DIY BIOS FlashBack button, BIOS FlashBack LED, Box headers, Clear CMOS button, CPU Socket lever protector, ProCool II, Pre-mounted I/O shield, SafeDIMM Aura Sync Addressable Gen2 headers Bespoke Motherboard Design & Business Focused Features 24/7 reliability, Overcurrent protection
Software Features	ASUS Exclusive Software Armoury Crate (Aura Creator, Aura Sync, Fan Xpert 4, Power Saving) ASUS Driver Hub ASUS GlideX ASUS CPU-Z CreatonFirst ProArt Creator Hub TurboV Core Thunderbolt Share USB Wattage Watcher Adobe Creative Cloud (Free Trial) Norton 360 Deluxe (60 Days Free Trial) WinRAR (40 Days Free Trial) UEFI BIOS AI Overclocking Guide ASUS EZ DIY (ASUS CrashFree BIOS 3, ASUS EZ Flash, ASUS UEFI BIOS EZ Mode, ASUS MyHotkey) NPU Boost Remote Management Features IT Management software supported – ASUS Control Center Express(ACCE)
BIOS	256 Mb Flash ROM, UEFI AMI BIOS
Manageability	WOL by PME, PXE
Accessories	Cables 2 x SATA 6Gb/s cables Miscellaneous 1 x ASUS WiFi Q-Antenna 1 x Q-connector 2 x M.2 Q-Latch packages 2 x M.2 rubber packages 1 x ProArt accessory bag Documentation 1 x ACC Express activation key card 1 x Quick start guide
Operating System	Windows 11 (22H2 & later)
Form Factor	ATX Form Factor
