GIGABYTE GeForce RTX 5060 EAGLE MAX OC 8GB GDDR7 Graphics Card
Sold Out
- Memory: 8GB GDDR7
- Processing Units: 3840 CUDA Cores
- Clock Speed: 2497 MHz (Base) | 2550 MHz (Boost)
- Memory Interface: 128-bit
- Display Outputs: 1 x HDMI 2.1b | 3 x DisplayPort 2.1b
- Warranty: 3 Years
Currently Out of Stock – Get Notified
- Description
- specs
- Brand
- Reviews (0)
Description
GIGABYTE GeForce RTX 5060 EAGLE MAX OC: Soar to New Heights
The GIGABYTE GeForce RTX 5060 EAGLE MAX OC 8GB combines futuristic aerospace aesthetics with the raw power of the NVIDIA Blackwell architecture. Designed for gamers and creators who demand performance and style, it features the advanced WINDFORCE cooling system to keep temperatures low while delivering exceptional 1080p and 1440p performance.
Unique Features
- Aerospace-Inspired Design: The EAGLE series features a streamlined appearance with segmented lines resembling spaceship deck components, infusing your build with a rich cosmic technology vibe.
- WINDFORCE Cooling System: Equipped with three alternate-spinning Hawk Fans, a copper plate, and composite heat pipes to ensure high-efficiency heat dissipation.
- Hawk Fan Design: The unique blade shape is inspired by an eagle’s wing, reducing air resistance and noise while significantly increasing airflow volume.
- Reinforced Structure: A sturdy backplate with a bent edge not only provides an aesthetic finish but also reinforces the structure of the graphics card to prevent PCB bending.
- Ultra Durable Components: Built with certified high-grade metal chokes, lower ESR solid capacitors, and low RDS(on) MOSFETs for superior performance and a longer system lifespan.
Powered by NVIDIA Blackwell Architecture
- NVIDIA DLSS 4: A revolutionary breakthrough in AI-powered graphics that multiplies performance, using 5th Generation Tensor Cores and Multi-Frame Generation for the smoothest gameplay.
- 4th Generation RT Cores: Delivers up to 2x the ray tracing performance of the previous generation, creating incredibly realistic and immersive game worlds with full ray tracing.
- NVIDIA Reflex 2: Optimises the graphics pipeline for ultimate responsiveness, providing the lowest latency for a competitive edge in fast-paced games.
- NVIDIA Studio: Unlock your creative potential with dedicated drivers and exclusive tools designed to accelerate your workflow in video editing, 3D rendering, and graphic design.
Quick Specs of the GIGABYTE GeForce RTX 5060 EAGLE MAX OC 8GB
| Specification | Details |
|---|---|
| Memory | 8GB GDDR7 | 128-bit |
| Memory Speed | 28 Gbps |
| CUDA Cores | 3840 |
| Architecture | NVIDIA Blackwell 2.0 |
| Interface | PCI Express 5.0 |
| Graphic Outputs | 1 x HDMI 2.1b | 3 x DisplayPort 2.1b |
| Maximum Resolution | 7680 x 4320 |
| Maximum Displays | 4 |
| Recommended PSU | 550W |
| Warranty | 3 Years |
Check out full specifications under the Specs tab.
Why Choose This Product?
The GIGABYTE GeForce RTX 5060 EAGLE MAX OC is the perfect choice for gamers who want a card that looks as good as it performs. Its unique sci-fi industrial design sets it apart, while the powerful WINDFORCE cooling system ensures it stays cool under pressure. With next-gen GDDR7 memory and the full suite of NVIDIA Blackwell features like DLSS 4, it offers a premium gaming experience that is ready for the future.
| I. Overview & Core Architecture | |
|---|---|
| Product Name | GIGABYTE GeForce RTX 5060 EAGLE MAX OC 8G |
| Model Name | GV-N5060EAGLEOC-8GD (Inferred) |
| Primary Colour | Grey / Black |
| GPU Manufacturer | NVIDIA |
| GPU Model / Chipset | GeForce RTX 5060 |
| Architecture | NVIDIA Blackwell 2.0 |
| PCIe Bandwidth | PCI Express 5.0 |
| RGB Lighting | Yes (Dynamic Pulsating Visual) |
| Manufacturer Warranty | 3 Years |
| II. GPU Performance Characteristics | |
| CUDA Cores | 3840 |
| Tensor Cores | 120 (5th Generation) |
| RT Cores | 30 (4th Generation) |
| Engine Clock Speeds | Boost Clock: 2550 MHz (Reference: 2497 MHz) |
| Overclocked Edition | Yes |
| III. Memory | |
| Memory Size | 8GB |
| Memory Type | GDDR7 |
| Memory Interface / Bus Width | 128-bit |
| Memory Clock Speed | 28 Gbps |
| Memory Bandwidth (Calculated) | 448 GB/s |
| IV. Display Outputs & Capabilities | |
| HDMI | 1x Native HDMI 2.1b |
| DisplayPort | 3x Native DisplayPort 2.1b |
| Maximum Digital Resolution | 7680 x 4320 |
| Maximum Displays Supported | 4 |
| HDCP Support | Yes |
| V. Supported APIs & Features | |
| DirectX Support | 12 Ultimate (12_2) |
| OpenGL Support | 4.6 |
| Key NVIDIA Features |
|
| Other Software/Hardware Features |
|
| VI. Cooling Solution | |
| Cooler Type / Design Name | WINDFORCE Cooling System |
| Number of Fans | 3 (Hawk Fans) |
| Fan Stop Technology | Yes (3D Active Fan) |
| Specific Cooling Technologies |
|
| VII. Power Requirements | |
| Recommended PSU | 550W |
| Power Consumption / TDP (Total Graphics Power) | 145W |
| Power Connectors | 1 x 8-pin |
| VIII. Physical Dimensions & Form Factor | |
| Card Dimensions (L x W x H or L x H x D) | 281 x 115 x 40 mm |
| Weight | 650 grams |
| Form Factor | Full Height |
| Slot Size / Width Required | 2 Slot |
| IX. Package Contents / Accessories | |
| What’s in the Box |
|
