GIGABYTE GeForce RTX 5090 WINDFORCE OC 32G GDDR7 Graphics Card
Sold Out
- Memory: 32GB GDDR7
- Processing Units: 21760 CUDA Cores
- Clock Speed: 2017 MHz (Base Clock) | 2467 MHz (Boost Clock)
- Memory Interface: 512-bit
- Display Outputs: 1 x HDMI | 3 x DisplayPort
- Warranty: 3 Years
Currently Out of Stock – Get Notified
- Description
- SPECS
- Brand
- Reviews (0)
Description
GIGABYTE GeForce RTX 5090 WINDFORCE OC: The Ultimate Gaming Powerhouse
The GIGABYTE GeForce RTX 5090 WINDFORCE OC 32GB is built on a foundation of performance and reliability. Powered by the groundbreaking NVIDIA Blackwell architecture, this card delivers the ultimate performance for 4K and 8K gaming. Its highly efficient WINDFORCE cooling system, featuring a large vapor chamber and durable components, makes it the ideal choice for any high-end gaming build.
Unique Features
- WINDFORCE Cooling System: Features innovative Hawk Fans with alternate spinning, a large vapor chamber, composite copper heat pipes, and screen cooling for exceptional heat dissipation.
- Large Vapor Chamber & Heat-Pipe: A large vapor chamber directly contacts the GPU and VRAM, coupled with composite copper heat pipes to quickly and efficiently transfer heat away from the core components.
- Hawk Fan Design: Inspired by the aerodynamics of an eagle’s wing, this unique blade design reduces air resistance and noise while increasing air pressure and volume.
- Reinforced Structure: The reinforced metal backplate not only provides an aesthetical shape but also enhances the structure of the graphics card to provide complete protection.
- Ultra Durable Components: Uses certified highest-grade metal chokes, lower ESR solid capacitors, and a 2oz copper PCB to deliver superior performance and a longer system life.
Powered by NVIDIA Blackwell Architecture
- NVIDIA DLSS 4: A revolutionary breakthrough in AI-powered graphics that multiplies performance, using 5th Generation Tensor Cores and Multi Frame Generation for the smoothest gameplay.
- 4th Generation RT Cores: Delivers up to 2x the ray tracing performance of the previous generation, creating incredibly realistic and immersive game worlds with full ray tracing and neural rendering.
- NVIDIA Reflex 2 with Frame Warp: Provides the lowest latency and best responsiveness for the ultimate competitive advantage in fast-paced games.
- 32GB GDDR7 Memory: An enormous VRAM buffer on a 512-bit bus to handle the most demanding 4K/8K game textures and intensive creative workloads with ease.
Quick Specs of the GIGABYTE GeForce RTX 5090 WINDFORCE OC 32GB
| Specification | Details |
|---|---|
| Memory | 32GB GDDR7 | 512-bit |
| Memory Speed | 28 Gbps |
| CUDA Cores | 21760 |
| Architecture | NVIDIA Blackwell 2.0 |
| Interface | PCIe 5.0 x16 |
| Graphic Outputs | 1 x HDMI 2.1b | 3 x DisplayPort 2.1b |
| Maximum Resolution | 7680×4320 |
| Maximum Displays | 4 |
| Recommended PSU | 1000W |
| Warranty | 3 Years |
Check out full specifications under the Specs tab.
Why Choose This Product?
The GIGABYTE GeForce RTX 5090 WINDFORCE OC is for the ultimate enthusiast gamer who wants raw performance without paying for extra aesthetic features. It provides the full power of the flagship RTX 5090 GPU, backed by a robust and reliable WINDFORCE cooling solution that ensures stable operation during the most demanding 4K and 8K gaming sessions.
This card leverages the full power of the next-generation Blackwell architecture, including the game-changing performance of DLSS 4. If you’re looking for a no-nonsense graphics card that delivers the absolute best performance, the WINDFORCE OC is the essential heart of your new build.
| I. Overview & Core Architecture | |
|---|---|
| Product Name | GIGABYTE GeForce RTX 5090 WINDFORCE OC 32G |
| Model Name | GV-N5090WF3OC-32GD |
| Primary Color | Black / Grey |
| GPU Manufacturer | NVIDIA |
| GPU Model / Chipset | GeForce RTX 5090 |
| Architecture | NVIDIA Blackwell 2.0 |
| PCIe Bandwidth | PCIe 5.0 x16 |
| RGB Lighting | No |
| Manufacturer Warranty | 3 Years |
| II. GPU Performance Characteristics | |
| CUDA Cores | 21760 |
| Tensor Cores | 680 (5th Generation) |
| RT Cores | 170 (4th Generation) |
| Engine Clock Speeds | Base Clock: 2017 MHz Boost Clock: 2467 MHz |
| Overclocked Edition | Yes |
| III. Memory | |
| Memory Size | 32 GB |
| Memory Type | GDDR7 |
| Memory Interface / Bus Width | 512 bit |
| Memory Clock Speed | 28 Gbps |
| Memory Bandwidth (Calculated) | 1792 GB/s |
| IV. Display Outputs & Capabilities | |
| HDMI | 1x HDMI 2.1b |
| DisplayPort | 3x DisplayPort 2.1b |
| Maximum Digital Resolution | 7680×4320 |
| Maximum Displays Supported | 4 |
| HDCP Support | Yes (2.3) |
| V. Supported APIs & Features | |
| DirectX Support | 12 Ultimate |
| OpenGL Support | 4.6 |
| Key NVIDIA Features |
|
| Other Software/Hardware Features |
|
| VI. Cooling Solution | |
| Cooler Type / Design Name | WINDFORCE Cooling System |
| Number of Fans | 3 |
| Fan Stop Technology | Yes (3D Active Fan) |
| Specific Cooling Technologies |
|
| VII. Power Requirements | |
| Recommended PSU | 1000W |
| Power Consumption / TDP (Total Graphics Power) | 575W |
| Power Connectors | 1 x 16-pin |
| VIII. Physical Dimensions & Form Factor | |
| Card Dimensions (L x W x H or L x H x D) | 342 x 150 x 65 mm |
| Weight | Not Specified |
| Form Factor | Full Height |
| Slot Size / Width Required | 3.25 Slot |
| IX. Package Contents / Accessories | |
| What’s in the Box |
|
